电动球阀DN50-PN10SolidWorks,step 三维模型
三维机械图纸名称为：电动球阀DN50-PN10，属于设备部件，管道附件分类，软件为SolidWorks,step, 三维模型格式为sldprt,sldasm,step，可在线预览，可编辑，可供设计参考
模型参数
模型ID：10554483
模型大小：1.66M
软件版本： SolidWorks,step
模型格式：sldprt,sldasm,step
是否可编辑：可修改，包括参数
上传时间：2026-08-12
图纸介绍：
下载模型
文件列表
1. DN50-PN10.JPG
108 KB
2. 承插法兰.SLDPRT
31.2 KB
3. 法兰.SLDPRT
30.6 KB
4. 球阀体.SLDPRT
51.5 KB
5. 电动执行器.SLDPRT
387 KB
6. 电动球阀DN50-PN10.JPG
153 KB
7. 电动球阀DN50-PN10.SLDASM
633 KB
8. 电动球阀DN50-PN10.STEP
1.98 MB
