内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组SolidWorks 三维模型
三维机械图纸名称为：内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组，属于设备部件，机床附件分类，软件为SolidWorks, 三维模型格式为sldprt,sldasm，可在线预览，可编辑，可供设计参考
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组主视图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_01_home.png!format.webp)
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组前视图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_02_front.png!format.webp)
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组后视图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_03_back.png!format.webp)
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组左视图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_04_left.png!format.webp)
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组右视图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_05_right.png!format.webp)
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组俯视图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_06_top.png!format.webp)
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组正等轴测图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_08_IsoMetric.png!format.webp)
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组主视缩略图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_01_home.png!format_w_520.webp)
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组前视缩略图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_02_front.png!format_w_520.webp)
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组后视缩略图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_03_back.png!format_w_520.webp)
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组左视缩略图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_04_left.png!format_w_520.webp)
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组右视缩略图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_05_right.png!format_w_520.webp)
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组俯视缩略图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_06_top.png!format_w_520.webp)
![内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组正等轴测缩略图](https://image.shanhu3d.com/images/101115410001/20260701/10521580_08_IsoMetric.png!format_w_520.webp)
模型参数
模型ID：10521580
模型大小：6.87M
软件版本： SolidWorks
模型格式：sldprt,sldasm
是否可编辑：可修改，包括参数
上传时间：2026-07-01
图纸介绍：
下载模型
文件列表
1. GTH5-BC.SLDPRT
413 KB
2. GTH5-BL-57.SLDPRT
369 KB
3. GTH5-BM-57.SLDPRT
283 KB
4. GTH5-BR-57.SLDPRT
370 KB
5. GTH5固定座.SLDPRT
292 KB
6. GTH5感应器组件1.SLDPRT
207 KB
7. GTH5感应器组件2.SLDPRT
198 KB
8. GTH5感应片.SLDPRT
142 KB
9. GTH5本体.SLDPRT
337 KB
10. GTH5滑台组件.SLDPRT
351 KB
11. GTH5轴承座.SLDPRT
252 KB
12. GTH5钢带压板.SLDPRT
126 KB
13. 内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组.sldasm
1.08 MB
14. 内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组_GTH5-BM-57.SLDPRT
283 KB
15. 内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组_GTH5固定座.SLDPRT
292 KB
16. 内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组_GTH5感应器组件1.SLDPRT
206 KB
17. 内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组_GTH5感应器组件2.SLDPRT
198 KB
18. 内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组_GTH5感应片.SLDPRT
141 KB
19. 内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组_GTH5本体.SLDPRT
337 KB
20. 内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组_GTH5滑台组件.SLDPRT
352 KB
21. 内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组_GTH5轴承座.SLDPRT
253 KB
22. 内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组_GTH5钢带压板.SLDPRT
126 KB
23. 内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组_宽头内六角螺丝.SLDPRT
75.1 KB
24. 内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组_雷赛57电机57HS22-A-21.SLDPRT
325 KB
25. 宽头内六角螺丝.SLDPRT
74.2 KB
26. 雷赛57电机57HS22-A-21.SLDPRT
324 KB
【内嵌式螺杆 GTH5-57闭环步进[GTH5-L2-300-BM-57-C2-N]丝杆滑台模组】相关作品
