LOT干泵HD120三维模型

图纸ID：10147135

文件大小：9.71M

软件版本：

SOLIDWORKS 2018

图纸格式：sldprt,sldasm,pdf

参数/编辑：可修改，包括参数

上传时间：2022-11-13

图纸介绍：

下载模型

九重宫阙

+ 关注

作品: 0

粉丝: 0

文件列表

1. 20013589_A_3-Bolt_ Stud _DIN 939Fo__ M12xL35_ Steel 8.8-zinc blue.sldprt

19.7 KB

2. 20076154_A_2-__X2_C18C_X0__Washer_ Flat_ M8 10.33x25.4x4.75t _SB_.sldprt

18.6 KB

3. 20076267_A_3-Regulator_ N2 5-100psig Small Size.sldprt

170 KB

4. 20103119_A_4-Bolt_ Hex socket head cap _DIN 912__ M8xL16_ Steel 12.9-_zinc blue.sldprt

23 KB

5. 20103120_A_4-Bolt_ Hex socket head cap _DIN 912__ M8xL20_ Steel 12.9-_zinc blue.sldprt

22.6 KB

6. 20103121_A_4-Bolt_ Hex socket head cap _DIN 912__ M8xL25_ Steel 12.9-_zinc blue.sldprt

22.1 KB

7. 21101115_A_3-Nut_ Hex _DIN 934__ M12_ Steel-zinc blue.sldprt

25.2 KB

8. 22101106_A_2-__X2_C18C_X0__Washer_ Flat_ M8 15.6x8.3x1._6t.sldprt

18.6 KB

9. 22101109_A_3-Washer_ Flat _DIN 125A__ M12_ Steel-zinc blue.sldprt

19.6 KB

10. 23194407_A_3-Centering_ Manifold Exhaust_ KF40_ STN.sldprt

20.8 KB

11. 23393301_B_1-Centering_ WH700 Adapter _LD1000P_ Outer_ NW63.sldprt

18.2 KB

12. 36116120_A_4-Flange_ WS501 Blower Inlet_ NW63_ SS41C.sldprt

23.7 KB

13. 43131240_A_3-Ring_ Retainer Manifold Exhaust_ KF40.sldprt

19.4 KB

14. 72138121_A_3-__X2_C18C_X0__Standoff Set_ Main Cable.sldprt

35.2 KB

15. 72322426_B_1-GUARD_PUSH-PULL OPERATOR.sldprt

44.3 KB

16. 72477545_A_3-Sight Glass_ Side Panel_ 69.8x39.7_ Polycarbonate.sldprt

22.7 KB

17. 7770026_A_2-Cap_ End_ NW40.sldprt

19.7 KB

18. 7770039_A_3-__X2_C18C_X0__Nut_ Hex_ M5_ SUS __X2_C0ACC6A9_X0_X__.sldprt

21.3 KB

19. 7770041_A_3-Washer_ EXT tooth lock _DIN 6797A__ M5_ SUS.sldprt

41.8 KB

20. 7770043_A_5-Bolt_ Hex socket head cap with Special low head __BN 1206___ M6xL10_ Steel 10.9-Nikel.sldprt

21.4 KB

21. 7770045_A_4-Bolt_ Hex socket head cap _DIN 912__ M6xL10_ SUS.sldprt

22.5 KB

22. 7770047_A_3-Bolt_ Flat countersunk head socket cap _DIN 7991__ M6xL10__ Steel 10.9-NiP.sldprt

22.3 KB

23. 7770049_A_3-Washer_ Spring _DIN 127B__ M8_ SUS.sldprt

21 KB

24. 7770056_A_6-Bolt_ Pan head___ 2Sems_ M3xL8_ Steel 4.8-zinc blue.sldprt

39.7 KB

25. 7770097_A_4-Bolt_ Hex socket head cap with Special low head __BN 1206___ M6xL16_ Steel 10.9-Nikel.sldprt

22.7 KB

26. 7780054_A_4-Quick Connector_ Nipple_Female__ 3_8NPT.sldprt

42.1 KB

27. 7780055_A_3-Quick Connector_ Coupler_Male__ 3_8NPT.sldprt

396 KB

28. 7810123_A_3-O-Ring_ Exhaust Manifold_ ID40.64x5.33t_NW40__ S-Viton_Wh_ite_.sldprt

21.9 KB

29. 7830002_B_3-Cover_ Inlet_ _X2_03A6_X0_163x3t_ Galvanized Steel Iron.sldprt

20.7 KB

30. 7830005_A_2-Plug_ Fitting Double FERL_ 1_4.sldprt

26.8 KB

31. 7843046_A_1-LED BOARD_ LD120L_ 140X140.sldprt

134 KB

32. 7860078_A_3-Connector_ Bulkhead Male_ 1_4-NPT 3_8_ SUS316.sldprt

48.8 KB

33. 7860088_A_2-Nut_ Regulator Panel Small Size_ Aluminium.sldprt

134 KB

34. 7862030_A_2-Leveler_ HD120_ FJSN10-75.sldprt

26.2 KB

35. 7862031_A_2-Caster_ HD120_600_1200 Front Revolving_ MISUMI.sldprt

91.8 KB

36. 7862032_A_2-Caster_ HD120_600_1200 Rear Stationary_ MISUMI.sldprt

56.9 KB

37. 7862038_1_2_A_1-FRONT FRAME HD120.sldprt

185 KB

38. 7862108_D_1-Manifold_ HD120_ 402mm-NW40_ SUS304L.sldprt

32.3 KB

39. 7862109_1_2_B_1-SUPPORT_ SIDE RIGHT_HD120_8 Cell.sldprt

127 KB

40. 7862110_1_2_A_2-SUPPORT_ SIDE LEFT_HD120_8 Cell.sldprt

127 KB

41. 7862111_B_3-Panel_ HD120 Top Front.sldprt

62.4 KB

42. 7862112_1_2_A_3-Panel_ HD120 Side Left.sldprt

30.5 KB

43. 7862113_1_2_C_1-Panel_ HD120 Side Right.sldprt

30.8 KB

44. 7862118_D_1-Base_ HD120_ 3t_ SPCC.sldprt

345 KB

45. 7863007_A_1-Keypad Assembly_ HD120.sldprt

1.12 MB

46. 7863009_A_1-Main Switch_ML1_40A_660Vac_Black_GE_MZ35029_.sldprt

163 KB

47. 7863013_B_1-EMO_Head__ZB4-BS44_Telemecanique.sldprt

36.9 KB

48. 7863500_D_1-Cable_Power Connector To Main Switch_L_1150.sldprt

93.5 KB

49. 7863620_HD120_A_1-Cable_Communication Cable_L_1100.sldprt

104 KB

50. 7864001_C_2-Plate_ HD120 Main Cable Assy.sldprt

85.3 KB

51. 7864004_1_2_A_3-Panel_ HD120 Rear.sldprt

142 KB

52. 7864005_A_2-Connector_ Union Bulkhead Type_ Tube 1_4.sldprt

34.7 KB

53. 7864007_1_2_B_1-Panel_ HD120 Front Elec Box.sldprt

86.1 KB

54. 7864010_A_2-Panel_ HD120 Top Rear.sldprt

24.7 KB

55. 7864011_A_2-Screw_ Male Support Skin_ M10xL12-M10xDP20_ S45C.sldprt

23.8 KB

56. 8046012_A_2-O-Ring_ ID72.39x5.33t_AS-568-336__ Viton.sldprt

22.7 KB

57. Bracket_ HD120 Seismic Kit Lower Ground_A_2.sldprt

24.5 KB

58. Bracket_ HD120 Seismic Kit Upper_A_2.sldprt

29.4 KB

59. HD120_Outline_A.SLDASM

4.22 MB

60. HD120_Outline_A.pdf

572 KB

61. N100022_A_2-Clamp_ End Gear Lock_ HLC-40A.sldprt

35.7 KB

62. PH7860024_F_1-Rotor Housing_ HD120 Cold_ GC250.sldprt

331 KB
