旋转闸门设计SolidWorks,step 三维模型
三维机械图纸名称为：旋转闸门设计，属于机械设备，非标机械分类，软件为SolidWorks,step, 三维模型格式为sldprt,sldasm,step，可在线预览，可编辑，可供设计参考
模型参数
模型ID：10555138
模型大小：2.72M
软件版本： SolidWorks,step
模型格式：sldprt,sldasm,step
是否可编辑：可修改，包括参数
上传时间：2026-08-12
图纸介绍：
免费下载
文件列表
1. 12mm Pin.sldprt
51 KB
2. Access Control Plate.sldprt
64.5 KB
3. Access Control.sldprt
159 KB
4. Bafle Gate Assembly.sldasm
39.5 KB
5. Bafle Plate Cover_plate_As Machined_.sldprt
59.5 KB
6. Bafle Plate_Default_As Machined_.sldprt
74 KB
7. Body Cover.sldprt
65 KB
8. Body Main.sldprt
117 KB
9. Body Side Cover.sldprt
66.5 KB
10. Body Top.sldprt
90 KB
11. Cam Plate.sldprt
56.5 KB
12. Cover Bottom Plate.sldprt
58.5 KB
13. Frame_Default_As Machined_.sldprt
230 KB
14. Latch.sldprt
56 KB
15. Mechanism Plate Cover.sldprt
55.5 KB
16. Mechanism Plate.sldprt
69.5 KB
17. MirrorCover Bottom Plate.sldprt
59 KB
18. NSK Flanged Bearing 25mm bore.sldprt
125 KB
19. Plug.sldprt
51 KB
20. Proximity Sensor.sldprt
53 KB
21. Shaft.sldprt
67 KB
22. Solenoid Arm.sldprt
56.5 KB
23. Solenoid Assembly.sldasm
46.5 KB
24. Solenoid Base.sldprt
54 KB
25. Solenoid Body.sldprt
56 KB
26. Solenoid Connection.sldprt
52.5 KB
27. Spacer Stainless.sldprt
53 KB
28. Spacer.sldprt
50 KB
29. circlip for shafts normal_din_Circlip DIN 471 - 10 x 1.sldprt
55.5 KB
30. flat head screw_am_B18.6.7M - M5 x 0.8 x 13 Type I Cross Recessed FHMS --13C.sldprt
57.5 KB
31. hex flange nut_din_Hexagon Flange Nut DIN 6923 - M16 - C.sldprt
76 KB
32. hex nut gradec_din_Hexagon Nut ISO 4034 - M10 - N.sldprt
59 KB
33. hex screw gradec_din_DIN EN 24018 - M10 x 30-WC.sldprt
61.5 KB
34. hex thin nut gradeb_din_Hexagon Nut ISO 4036 - M3 - N.sldprt
53 KB
35. pan head cross collar screw_din_DIN 967 - M3 x 30 - Z --- 29C.sldprt
65 KB
36. 【屿双网】Bafle Gate Assembly.STEP
4.83 MB
37. 【屿双网】旋转闸门设计模型.SLDASM
959 KB
