| # | 文件名称 | 文件大小 |
|---|---|---|
| 1 | 000 ASSEMBLY.SLDASM | 3.79 MB |
| 2 | 001 FRAME ASSY.sldasm | 129 KB |
| 3 | 002 TUBE ASSY.sldasm | 110 KB |
| 4 | 003 SCREW CONVEYOR.sldasm | 105 KB |
| 5 | 004 TOP COVER ASSY.sldasm | 122 KB |
| 6 | 006 BUCKET ASSY.sldasm | 102 KB |
| 7 | 01 STEEL L PROFILE 40X40X1750.sldprt | 46 KB |
| 8 | 02 STEEL L PROFILE 40X40X594.sldprt | 46.5 KB |
| 9 | 03 STEEL L PROFILE 40X40X588.sldprt | 46.5 KB |
| 10 | 04 TOP TUBE.sldprt | 58.5 KB |
| 11 | 05.MIDDLE TUBE.sldprt | 48.5 KB |
| 12 | 06 BOTTOM TUBE.sldprt | 46 KB |
| 13 | 07 BASE.sldprt | 48.5 KB |
| 14 | 08 MOUNT SCREW CONVEYOR.sldprt | 46 KB |
| 15 | 09 SHAFT FOR SCREW CONVEYOR.sldprt | 44 KB |
| 16 | 10 HELIX FOR SCREW CONVEYOR.sldprt | 262 KB |
| 17 | 100 ASSEMBLY CONTROL BOX.sldasm | 119 KB |
| 18 | 101 HOUSING CONTROL BOX.sldprt | 89 KB |
| 19 | 102 DOOR.sldprt | 60.5 KB |
| 20 | 103 LED INDICATOR GREEN_Green.sldprt | 62.5 KB |
| 21 | 104 LED INDICATOR RED_Green.sldprt | 62.5 KB |
| 22 | 105 ROTARY SWITCH LAY37-11X.sldprt | 251 KB |
| 23 | 106 PUSH BUTTON ON.sldprt | 84.5 KB |
| 24 | 107 PLATE BUTTON ON.sldprt | 70.5 KB |
| 25 | 108 PUSH BUTTON OFF_-01.sldprt | 83 KB |
| 26 | 109 PLATE BUTTON OFF.sldprt | 74 KB |
| 27 | 11 EXTENSION FOR SCREW CONVEYOR.sldprt | 44.5 KB |
| 28 | 110 PUSH EMERGENCY BUTTON.sldprt | 79.5 KB |
| 29 | 111 PLATE EMERGENCY BUTTON_-01.sldprt | 259 KB |
| 30 | 112 SAFETY PLATE FOR EMERGENCY.sldprt | 164 KB |
| 31 | 12 INSIDE TUBE.sldprt | 44 KB |
| 32 | 13 OUTPUT CANAL.sldprt | 51 KB |
| 33 | 14 COVER OUTPUT CANAL.sldprt | 48 KB |
| 34 | 15 INPUT TANK.sldprt | 49.5 KB |
| 35 | 16 FILTER PLATE BOTTOM.sldprt | 60 KB |
| 36 | 17 HOLDER FOR INSIDE TUBE.sldprt | 56 KB |
| 37 | 18 STEEL L PROFILE 40X40X206.sldprt | 46 KB |
| 38 | 19 STEEL L PROFILE 40X40X300.sldprt | 46.5 KB |
| 39 | 20 PLATE TOP COVER.sldprt | 51.5 KB |
| 40 | 21 STEEL L PROFILE 30X30X785.sldprt | 47 KB |
| 41 | 22 DOOR FOR TOP COVER.sldprt | 59 KB |
| 42 | 23 RADIAL BEARING UCF 205_Vychoz_.sldprt | 136 KB |
| 43 | 24 HINGE SHAFT FOR DOOR TOP COVER.sldprt | 44 KB |
| 44 | 25 MOTOR 1 PHASE.sldprt | 1.68 MB |
| 45 | 26 STEEL L PROFILE 40X40X174.sldprt | 46 KB |
| 46 | 27 STEEL L PROFILE 40X40X680.sldprt | 47.5 KB |
| 47 | 27 STEEL L PROFILE 40X40X680_2.sldprt | 47.5 KB |
| 48 | 28 STEEL L PROFILE 40X40X108.sldprt | 46.5 KB |
| 49 | 28 STEEL L PROFILE 40X40X108_2.sldprt | 46 KB |
| 50 | 29 STEEL L PROFILE 40X40X102.sldprt | 47 KB |
| 51 | 31 DRIVEN PULLEY.sldprt | 74 KB |
| 52 | 32 DRIVING PULLEY.sldprt | 48 KB |
| 53 | 33 SLOT ADJUSTER.sldprt | 46.5 KB |
| 54 | 34 BUCKET.sldprt | 51.5 KB |
| 55 | 35 BUCKET HOLDER.sldprt | 52.5 KB |
| 56 | 36 ROUND GLASS.sldprt | 49 KB |
| 57 | Belt1-1^000 ASSEMBLY.sldprt | 48.5 KB |
| 58 | SY_60_TR.sldprt | 312 KB |
| 59 | hex bolt gradeab_iso_ISO 4014 - M10 x 45 x 26-N.sldprt | 54 KB |
| 60 | hex bolt gradeb_iso_ISO 4015 - M6 x 25 x 18-N.sldprt | 50.5 KB |
| 61 | hex bolt gradeb_iso_ISO 4015 - M8 x 30 x 22-N.sldprt | 50.5 KB |
| 62 | hex flange bolt small_iso_ISO 4162 - M12 x 35 x 35-N.sldprt | 66 KB |
| 63 | hex flange nut gradea_iso_ISO - 4161 - M10 - N.sldprt | 66.5 KB |
| 64 | hex nut gradec_iso_ISO - 4034 - M10 - N.sldprt | 52.5 KB |
| 65 | hex nut gradec_iso_ISO - 4034 - M6 - N.sldprt | 52.5 KB |
| 66 | hex nut gradec_iso_ISO - 4034 - M8 - N.sldprt | 52.5 KB |
| 67 | hex nut style 1 gradeab_iso_ISO - 4032 - M12 - W - N.sldprt | 52.5 KB |
| 68 | thrust ball bearing_68_skf_SKF - 51307 - 10,SI,NC,10_68.sldprt | 52 KB |
简易立式搅拌机
图纸ID：10199583
文件大小：6.65M
软件版本：
图纸格式：sldasm,sldprt
参数/编辑：可修改，包括参数
上传时间：2024-07-02
图纸介绍：
