QGB系列标准气缸[QGA63X200]SolidWorks 三维模型
三维机械图纸名称为：QGB系列标准气缸[QGA63X200]，属于设备部件，液压气动元件分类，软件为SolidWorks, 三维模型格式为sldprt,sldasm，可在线预览，可编辑，可供设计参考
![QGB系列标准气缸[QGA63X200]主视图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_01_home.png!format.webp)
![QGB系列标准气缸[QGA63X200]前视图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_02_front.png!format.webp)
![QGB系列标准气缸[QGA63X200]后视图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_03_back.png!format.webp)
![QGB系列标准气缸[QGA63X200]左视图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_04_left.png!format.webp)
![QGB系列标准气缸[QGA63X200]右视图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_05_right.png!format.webp)
![QGB系列标准气缸[QGA63X200]俯视图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_06_top.png!format.webp)
![QGB系列标准气缸[QGA63X200]正等轴测图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_08_IsoMetric.png!format.webp)
![QGB系列标准气缸[QGA63X200]主视缩略图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_01_home.png!format_w_520.webp)
![QGB系列标准气缸[QGA63X200]前视缩略图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_02_front.png!format_w_520.webp)
![QGB系列标准气缸[QGA63X200]后视缩略图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_03_back.png!format_w_520.webp)
![QGB系列标准气缸[QGA63X200]左视缩略图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_04_left.png!format_w_520.webp)
![QGB系列标准气缸[QGA63X200]右视缩略图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_05_right.png!format_w_520.webp)
![QGB系列标准气缸[QGA63X200]俯视缩略图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_06_top.png!format_w_520.webp)
![QGB系列标准气缸[QGA63X200]正等轴测缩略图](https://image.shanhu3d.com/images/101115419701/20260906/10578660_08_IsoMetric.png!format_w_520.webp)
模型参数
模型ID：10578660
模型大小：3.62M
软件版本： SolidWorks
模型格式：sldprt,sldasm
是否可编辑：可修改，包括参数
上传时间：2026-09-06
图纸介绍：
免费下载
文件列表
1. QGA、QGB-SD杆.SLDPRT
474 KB
2. QGA、QGB-SD缸体.SLDPRT
1.46 MB
3. QGB系列标准气缸[QGA63X200].sldasm
475 KB
4. QGB系列标准气缸[QGA63X200]_QGA、QGB-SD杆.sldprt
475 KB
5. QGB系列标准气缸[QGA63X200]_QGA、QGB-SD缸体.sldprt
740 KB
【QGB系列标准气缸[QGA63X200]】相关作品
