DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]SolidWorks 三维模型
三维机械图纸名称为：DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]，属于设备部件，电机减速机分类，软件为SolidWorks, 三维模型格式为sldprt,sldasm，可在线预览，可编辑，可供设计参考
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]主视图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_01_home.png!format.webp)
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]前视图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_02_front.png!format.webp)
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]后视图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_03_back.png!format.webp)
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]左视图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_04_left.png!format.webp)
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]右视图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_05_right.png!format.webp)
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]俯视图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_06_top.png!format.webp)
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]正等轴测图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_08_IsoMetric.png!format.webp)
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]主视缩略图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_01_home.png!format_w_520.webp)
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]前视缩略图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_02_front.png!format_w_520.webp)
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]后视缩略图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_03_back.png!format_w_520.webp)
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]左视缩略图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_04_left.png!format_w_520.webp)
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]右视缩略图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_05_right.png!format_w_520.webp)
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]俯视缩略图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_06_top.png!format_w_520.webp)
![DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]正等轴测缩略图](https://image.shanhu3d.com/images/101115421501/20260628/10517625_08_IsoMetric.png!format_w_520.webp)
模型参数
模型ID：10517625
模型大小：7.97M
软件版本： SolidWorks
模型格式：sldprt,sldasm
是否可编辑：可修改，包括参数
上传时间：2026-06-28
图纸介绍：
下载模型
文件列表
1. 42步进电机.SLDPRT
208 KB
2. DMB45-L66S200-DT400-C2D-RBCR-M.SLDASM
2.56 MB
3. DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR].sldasm
425 KB
4. DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]_复件 45传感器组件-M.sldasm
124 KB
5. DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]_复件 45底座-S200-LBCR-M.sldprt
412 KB
6. DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]_复件 45滑动座SCR-A.sldprt
538 KB
7. DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]_复件 45电机转折部分-M.sldprt
183 KB
8. DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]_复件 台达ECMA-C20401S伺服电机-DT100-M.sldprt
171 KB
9. DMB45-RBCR同步带模组直线模组（电机右后折）[DMB45-L66S300-DT100-C2U-RBCR]_复件 防护罩45x86.sldprt
173 KB
10. 三菱HF-KN13JK伺服电机-MT100.SLDPRT
253 KB
11. 三菱HF-KN13JK伺服电机-MT100B.SLDPRT
291 KB
12. 台达ECMA-C20401BS伺服电机-DT100B.SLDPRT
251 KB
13. 复件 45传感器组件-M.sldasm
124 KB
14. 复件 45底座-S200-LBCR-M.sldprt
419 KB
15. 复件 45滑动座SCR-A.sldprt
536 KB
16. 复件 45电机转折部分-M.sldprt
183 KB
17. 复件 EEE-674 感应器装配-M.sldprt
147 KB
18. 复件 EEE-674 感应器装配_1M.sldprt
140 KB
19. 复件 台达ECMA-C20401S伺服电机-DT100-M.sldprt
173 KB
20. 复件 感应片8.5x28x30-M.sldprt
62.6 KB
21. 复件 防护罩45x86.sldprt
173 KB
22. 松下MSME012G1伺服电机-PS100.SLDPRT
255 KB
23. 松下MSME012G1伺服电机-PS100B.SLDPRT
256 KB
