带前法兰的液压缸SolidWorks 三维模型
三维机械图纸名称为：带前法兰的液压缸，属于设备部件，液压气动元件分类，软件为SolidWorks, 三维模型格式为sldprt,sldasm，可在线预览，可编辑，可供设计参考
模型参数
模型ID：10445146
模型大小：1.89M
软件版本： SolidWorks
模型格式：sldprt,sldasm
是否可编辑：可修改，包括参数
上传时间：2026-05-04
图纸介绍：
下载模型
文件列表
1. Cushioning Sleeve-S4869.SLDPRT
106 KB
2. Cylinder-S4869.SLDPRT
47.6 KB
3. End Cap-S4869.SLDPRT
180 KB
4. Front Fixation Flange-S4869.SLDPRT
112 KB
5. Front-End Flange Fixation-S4869.SLDPRT
93.8 KB
6. Gland-S4869.SLDPRT
227 KB
7. Oil Grace-S4869.SLDPRT
125 KB
8. Piston Nut-S4869.SLDPRT
84.8 KB
9. Piston-S4869.SLDPRT
112 KB
10. Rod-S4869.SLDPRT
75.4 KB
11. S4869.SLDASM
374 KB
12. S4869.SLDDRW
414 KB
【带前法兰的液压缸】相关作品
