MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]SolidWorks 3D模型
机械图纸名称为：MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]，属于设备部件，液压气动元件分类，软件为SolidWorks, 三维模型格式为sldasm,sldprt，可在线预览，可编辑，可供设计参考
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]主视图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_01_home.png!format.webp)
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]前视图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_02_front.png!format.webp)
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]后视图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_03_back.png!format.webp)
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]左视图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_04_left.png!format.webp)
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]右视图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_05_right.png!format.webp)
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]俯视图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_06_top.png!format.webp)
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]正等轴测图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_08_IsoMetric.png!format.webp)
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]主视缩略图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_01_home.png!format_w_520.webp)
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]前视缩略图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_02_front.png!format_w_520.webp)
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]后视缩略图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_03_back.png!format_w_520.webp)
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]左视缩略图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_04_left.png!format_w_520.webp)
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]右视缩略图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_05_right.png!format_w_520.webp)
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]俯视缩略图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_06_top.png!format_w_520.webp)
![MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]正等轴测缩略图](https://image.shanhu3d.com/images/101115489001/20260422/10422952_08_IsoMetric.png!format_w_520.webp)
模型参数
模型ID：10422952
模型大小：2.05M
软件版本： SolidWorks
模型格式：sldasm,sldprt
是否可编辑：可修改，包括参数
上传时间：2026-04-22
图纸介绍：
免费下载
文件列表
1. MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT].sldasm
128 KB
2. MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]_杆.sldprt
190 KB
3. MBL╱MBLC铝合金迷你气缸[MBL25×100-SCAT]_缸体.sldprt
435 KB
4. 杆.SLDPRT
189 KB
5. 缸体.SLDPRT
1.11 MB
