美标截止阀，3”300LBAutoCAD,SolidWorks图档
CAD图档名称为：美标截止阀，3”300LB，属于设备部件，管道附件分类，软件为AutoCAD,SolidWorks, 图纸格式为dwg,sldasm,sldprt，可在线预览，可编辑，可供设计参考
模型参数
模型ID：10220112
模型大小：3.03M
软件版本： AutoCAD 2012,SolidWorks
模型格式：dwg,sldasm,sldprt
是否可编辑：可修改，包括参数
上传时间：2024-08-04
图纸介绍：
下载模型
文件列表
1. 3'J41Y-300LB-00.dwg
142 KB
2. 3DJBB4F1Y-300LB09G.SLDASM
2.28 MB
3. B型填料压套(26).sldprt
44 KB
4. GB_FASTENER_WASHER_SMWC 16.sldprt
43 KB
5. GB_HEXAGON_TYPE13 M16 Normal Style-C.sldprt
49.5 KB
6. Leher.SLDPRT
290 KB
7. double end studs bm=1.25d gb(GB_FASTENER_BOLT_DESBB A M16X65-N).sldprt
45 KB
8. eye bolts gb(GB_FASTENER_BOLT_LNB M12X80-C).sldprt
47.5 KB
9. hex nuts, style 2-grades ab gb(GB_HEXAGON_TYPE13 M12 Normal Style-C).sldprt
49.5 KB
10. hex nuts, style 2-grades ab gb(GB_HEXAGON_TYPE13 M16 Normal Style-C).sldprt
49.5 KB
11. parallel pins hardening steel gb(GB_CONNECTING_PIECE_PIN_DP 10X30).sldprt
44 KB
12. plain washers--product grade c gb(GB_FASTENER_WASHER_SMWC 12).sldprt
43.5 KB
13. tl.sldprt
43 KB
14. 上密封(d26).sldprt
48 KB
15. 中道垫片.sldprt
43 KB
16. 填料压板(26).sldprt
57.5 KB
17. 截止阀铜螺母(d26).sldprt
85.5 KB
18. 手轮.sldprt
228 KB
19. 阀体.sldprt
87 KB
20. 阀杆.sldprt
150 KB
21. 阀瓣.sldprt
46.5 KB
22. 阀瓣盖.sldprt
45 KB
23. 阀盖.sldprt
85.5 KB
