机械设备 / 非标机械 / 挤出机direct-extruder-INVENTOR

平面图

3D视图

文件列表

珊瑚网 www.shanhu3d.com

珊瑚网 www.shanhu3d.com

珊瑚网

#	文件名称	文件大小
1	ANSI B 18.2.4.1 M - M3 x 0,5Style 1.ipt	171 KB
2	ANSI B18.3.4M - M3 x 0.5 x 10(1).ipt	194 KB
3	ANSI B18.3.4M - M3 x 0.5 x 12(1).ipt	191 KB
4	ANSI B18.3.4M - M3 x 0.5 x 6(1).ipt	199 KB
5	Bearing 5x3x2.5.ipt	119 KB
6	Bottom.ipt	1.09 MB
7	CR10-1.ipt	174 KB
8	CR10-Fan-1.ipt	1.82 MB
9	CR10-Fan-2.ipt	1.62 MB
10	CR10.ipt	728 KB
11	Ceramic Cartridge Heater.ipt	133 KB
12	China 2nd.gear.ccopy.ipt	2.19 MB
13	Direct extruder1.iam	1.32 MB
14	Direct extruder2.iam	434 KB
15	E3D V6 Fan mount.ipt	1.2 MB
16	E3D.V6-1.75mm.iam	508 KB
17	ED005_Prof_20x20-5.ipt	207 KB
18	FAN 30X10 24V.iam	236 KB
19	Fan-30x30x10 24V.ipt	202 KB
20	Fan-Box-30x30x10 24V.ipt	200 KB
21	GT_Мотор Nema17s.ipt	866 KB
22	Heatbreak^E3D.V6-1.75mm_0.3Nozzle_wPushIn_Bowden.ipt	917 KB
23	Heater_Block^E3D.V6-1.75mm_0.3Nozzle_wPushIn_Bowden.ipt	140 KB
24	Heatsink^E3D.V6-1.75mm_0.3Nozzle_wPushIn_Bowden.ipt	252 KB
25	INSERT 3d.ipt	319 KB
26	K3x5x7.ipt	248 KB
27	Lever screw.ipt	164 KB
28	Lever.ipt	444 KB
29	Lock_washer_Nylon.ipt	120 KB
30	M3.ipt	264 KB
31	MGN9-H-Block.iam	161 KB
32	MGN9_rail_300mm.ipt	186 KB
33	Motor gear.ipt	781 KB
34	Nozzle 0.3mm^E3D.V6-1.75mm_0.3Nozzle_wPushIn_Bowden.ipt	341 KB
35	Plastic gear.ipt	1020 KB
36	Shaft 3- 20 mm.ipt	91.5 KB
37	Shaft 3- 32 mm.ipt	86.5 KB
38	Spring 2 1,0X5X10,8.ipt	419 KB
39	Top.ipt	949 KB
40	_PC6-01^Bowden Fitting 1.75.ipt	203 KB
41	cap001.ipt	95.5 KB
42	cap002.ipt	95.5 KB
43	direct extruder.png	454 KB
44	fan 40mm 12 volt.ipt	403 KB
45	main.ipt	135 KB
46	mid001.ipt	95 KB
47	mid002.ipt	94.5 KB
48	socket head cap screw_din_DIN 912 M2 x 12 --- 12C.ipt	124 KB
49	socket head cap screw_din_DIN 912 M2.5 x 4 --- 4C.ipt	148 KB
50	На СК10S.iam	2.66 MB

加入收藏

挤出机direct-extruder-INVENTOR

图纸ID：10200287

文件大小：23.15M

软件版本：

INVENTOR

图纸格式：ipt

参数/编辑：可修改，包括参数

上传时间：2024-07-06

图纸介绍：

下载模型
