| # | 文件名称 | 文件大小 |
|---|---|---|
| 1 | 20f-Carb Float Bowl Gasket-g.CATPart | 134 KB |
| 2 | 20g-Carburetor_BOTTOM half-SandS Super E shorty-g.CATPart | 2.78 MB |
| 3 | 20h-Carburetor_TOP half-SandS Super E shorty-g.CATPart | 6.21 MB |
| 4 | 20i-Bottom Bowl Plug-Brass-g.CATPart | 338 KB |
| 5 | 20j-Bottom Mounting Studs-Short Brass-g.CATPart | 427 KB |
| 6 | 20k-Bottom Mounting Studs-Long Brass-X1-g.CATPart | 436 KB |
| 7 | 20m-Fuel Inlet and float seat fitting-brass-g.CATPart | 429 KB |
| 8 | 20n-O_ring-for bottom plug and seat fittings-g.CATPart | 43.1 KB |
| 9 | 20p-Overflow fitting-g.CATPart | 280 KB |
| 10 | 20q-Mid-range jet adjuster screw-g.CATPart | 1.16 MB |
| 11 | 20r-Throttle and High Range jet Adjuster Screw-g.CATPart | 1.1 MB |
| 12 | 20s-Left Throttle Shaft Spring-g.CATPart | 384 KB |
| 13 | 20u-Throttle Cable spool-g.CATPart | 285 KB |
| 14 | 20v-Throttle Shaft Lock Washer-g.CATPart | 51.8 KB |
| 15 | 20w-Jet Bellows-g.CATPart | 89.6 KB |
| 16 | 20x-Right Throttle Shaft Spring-g.CATPart | 0 B |
| 17 | 20y-Pump Actuator Lever-g.CATPart | 120 KB |
| 18 | 20z-Pump Actuator Arm-g.CATPart | 93 KB |
| 19 | 35 to 40 Ford Spindle-rod 2-g.CATPart | 248 KB |
| 20 | 3rd member-rod 2-g.CATPart | 709 KB |
| 21 | 5487dff0f25ed.jpg | 39.8 KB |
| 22 | 5487dff320b8a.jpg | 61.2 KB |
| 23 | 9 inch pin support-rod 2-g.CATPart | 204 KB |
| 24 | Caliper Mount Bracket-rod 2-g.CATPart | 131 KB |
| 25 | Driver Steering Arm-rod 2-g.CATPart | 114 KB |
| 26 | Driver Steering Arm-rod 2-g_sym 2.CATPart | 110 KB |
| 27 | Ford 9in carrier-rod 2-g.CATPart | 681 KB |
| 28 | RESSORT AV.CATPart | 247 KB |
| 29 | Right Brake Caliper Bracket-rod 2-g.CATPart | 108 KB |
| 30 | _NPart#27087.CATPart | 41.6 KB |
| 31 | _NPart#342098.CATPart | 58.5 KB |
| 32 | _NPart#68802.CATPart | 102 KB |
| 33 | _NPart#701015.CATPart | 546 KB |
| 34 | _NPart#833490.CATPart | 0 B |
| 35 | accerr-carbsp-g_lat.CATPart | 316 KB |
| 36 | amortisseur ar part1-g.CATPart | 113 KB |
| 37 | amortisseur ar part2-g.CATPart | 95 KB |
| 38 | amortisseur.CATPart | 211 KB |
| 39 | arbre -g.CATPart | 53.1 KB |
| 40 | attache ressort.CATPart | 62 KB |
| 41 | axe dir.CATPart | 75 KB |
| 42 | axle tube-rod 2-g.CATPart | 286 KB |
| 43 | barre de direction 1.CATPart | 83.8 KB |
| 44 | blockv8-carbsp-g.CATPart | 1.5 MB |
| 45 | boitier dir 2.CATPart | 116 KB |
| 46 | boitier dir.CATPart | 234 KB |
| 47 | bombaHD-carbsp-g.CATPart | 244 KB |
| 48 | cablebujias-carbsp sym-g.CATPart | 1.3 MB |
| 49 | cablebujias-carbsp-g.CATPart | 0 B |
| 50 | cache culbu-g.CATPart | 683 KB |
| 51 | cache pot.CATPart | 541 KB |
| 52 | cardan -g.CATPart | 58.4 KB |
| 53 | carter-carbsp-g.CATPart | 344 KB |
| 54 | correa-carbsp-g.CATPart | 79.1 KB |
| 55 | coupe ford 1940 frame.CATPart | 687 KB |
| 56 | coupe ford 1940.CATPart | 11 MB |
| 57 | culata1-carbsp-g.CATPart | 743 KB |
| 58 | culata1_mir-carbsp-g.CATPart | 781 KB |
| 59 | cylinblock.CATPart | 46.1 KB |
| 60 | distribuidor-carbsp-g.CATPart | 223 KB |
| 61 | entretoise.CATPart | 44.1 KB |
| 62 | entretoise2.CATPart | 44.2 KB |
| 63 | exhaust3-g.CATPart | 1.26 MB |
| 64 | exhaust3-g_sym.CATPart | 2.53 MB |
| 65 | fillister head screw_ai_SL-FIMS 0.164-32x0.25x0.25-S.CATPart | 119 KB |
| 66 | front axle gasser.CATPart | 254 KB |
| 67 | heavy hex nut_ai_HHNUT 0.25-20-D-S.CATPart | 116 KB |
| 68 | hex bolt gradec_iso_ISO 4016 - M6 x 30 x 18-NN.CATPart | 66 KB |
| 69 | hex nut style 1 gradeab_iso_Hexagon Nut ISO - 4032 - M10 - W - N.CATPart | 80.1 KB |
| 70 | hex nut style 1 gradeab_iso_Hexagon Nut ISO - 4032 - M12 - W - N.CATPart | 80.3 KB |
| 71 | hex nut style 1 gradeab_iso_Hexagon Nut ISO - 4032 - M16 - W - N.CATPart | 80.5 KB |
| 72 | hex nut style 1 gradeab_iso_Hexagon Nut ISO - 4032 - M8 - W - N.CATPart | 79.6 KB |
| 73 | hex screw gradeab_iso_ISO 4017 - M10 x 40-N.CATPart | 81.9 KB |
| 74 | hex screw gradeab_iso_ISO 4017 - M10 x 60-N.CATPart | 81.2 KB |
| 75 | hex screw gradeab_iso_ISO 4017 - M12 x 40-N.CATPart | 82 KB |
| 76 | hex screw gradeab_iso_ISO 4017 - M12 x 65-N.CATPart | 81.7 KB |
| 77 | hex screw gradeab_iso_ISO 4017 - M16 x 60-N.CATPart | 82.1 KB |
| 78 | hex screw gradeab_iso_ISO 4017 - M16 x 70-N.CATPart | 82 KB |
| 79 | hex screw gradeab_iso_ISO 4017 - M8 x 20-N.CATPart | 81.8 KB |
| 80 | hex screw gradeab_iso_ISO 4017 - M8 x 25-N.CATPart | 82 KB |
| 81 | housing-carbsp-g.CATPart | 1.87 MB |
| 82 | jante ar amrc.CATPart | 2.72 MB |
| 83 | jante av amrc.CATPart | 1.77 MB |
| 84 | left side axle-rod 2-g.CATPart | 102 KB |
| 85 | pernos-carbsp-g_lat.CATPart | 2.92 MB |
| 86 | plain washer normal grade a_iso_Washer ISO 7089 - 10.CATPart | 48.8 KB |
| 87 | plain washer normal grade a_iso_Washer ISO 7089 - 6.CATPart | 48.9 KB |
| 88 | poleas-carbsp-g.CATPart | 281 KB |
| 89 | pr air 2.CATPart | 175 KB |
| 90 | qlternador-carbsp-g.CATPart | 2.06 MB |
| 91 | radiateur.CATPart | 9.75 MB |
| 92 | remschijf.CATPart | 4.09 MB |
| 93 | resort amor-g.CATPart | 872 KB |
| 94 | right side axle-rod 2-g.CATPart | 102 KB |
| 95 | sol.CATPart | 38 KB |
| 96 | soperthyd-carbsp-g.CATPart | 150 KB |
| 97 | soprtealtern-carbsp-g.CATPart | 115 KB |
| 98 | tapadistri-carbsp-g.CATPart | 855 KB |
| 99 | tapafrontal-carbsp-g.CATPart | 282 KB |
| 100 | tremec-carbsp-g.CATPart | 2.27 MB |
| 101 | water-carbsp-g.CATPart | 1.05 MB |
| 102 | zpt.CATProduct | 337 KB |
| 103 | ╨┬╜¿╬─▒╛╬─╡╡.txt | 122 B |
1182福特老爷车CATIAV5R21设计catia 3D模型
图纸ID：10185313
文件大小：30.31M
软件版本：
参数/编辑：可修改，包括参数
上传时间：2024-06-17
图纸介绍：
