带滑块的座外球面球球轴承catia 三维模型
三维机械图纸名称为：带滑块的座外球面球球轴承，属于设备部件，传动部件分类，软件为catia, 三维模型格式为，可在线预览，可编辑，可供设计参考
模型参数
模型ID：10173613
模型大小：179.41KB
软件版本： catia
是否可编辑：可修改，包括参数
上传时间：2024-04-13
图纸介绍：
免费下载
文件列表
1. bearing_asm.CATProduct
51.4 KB
2. bearing_in.CATPart
93.2 KB
3. bearing_out.CATPart
104 KB
4. bearing_ring.CATPart
238 KB
5. boll.CATPart
71.5 KB
6. 使用说明.txt
1.07 KB
7. 播放说明.html
4.08 KB
